1998 WEINIG MOULDER U23E Unimat

Weinig Unimat Molder 23E 4 sided plaining and moulding Machine Base, Tables, Fences: Machine frame made of vibration-absorbing and nondeforming heavy cast-iron elements. Ground fences and table plates, adjustable to tool cutting circle. Table plates easily interchangeable. Slotted table plates in from of and after 1st bottom spindle for noise reduction. Hardened table plate before 1st bottom spindle. Accurate and fast adjustment of straightening table and right edge jointing fence to required shop removal. Left fences adjustable in-out and up-down. Outfeed table adjustable for chip removal by the last bottom spindle of 0.5mm (0.020”) or 0.000 mm/“. Manual waxilit pump for table lubrication. Driven roller in the outfield table. SPINDLE CONFIGURATION: FEED MOTOR - 5.5HP 1ST SPINDLE BELOW - 10HP 2ND/3RD SPINDLE RIGHT/LEFT - 20 HP 4TH SPINDLE ABOVE - 20HP 5TH SPINDLE ABOVE - 15HP 6TH SPINDLE BELOW - 15HP MACHINE INCLUDES THE FOLLOWING EQUIPMENT: Heavy cast iron base Pneumatic spindle clamping, both axial and radial. Receding chipbreaker for top spindles 4 and 5, shipbreaker fully adjustable. Pneumatically pressurized feed rollers Driven table roller in the outfeed table, height adjustable Driven table roller after first bottom spindle. Driven table roller between the two top spindles Reference engraver for 1st bottom spindle Side pressure roller opposite right spindle Guarded first bottom spindle moving with the left spindle Digi-set for left and both top spindles Mechanical digital read-out for pressure shoe on both top spindles Central location of lubrications points Side pressure roller before indeed. Hardened table insert before and after 1st bottom top spindles 4, 5 Vertical spindle table plates easily adjustable to the cutting circle Prepared for 10 1/4” (260mm) wide planing including Feed wheel shafts are extended in length Chipbreaker extended in width Pressure shoe extended in width Table plates extended in width Reduced distance between feed rollers Measuring stand for tooling radius
